2013 popular PP-R fittings and pipe Elbow 90D from China manufacturer

Price:	1.0~20.0 USD
Payment Terms:	T/T,L/C,D/A,D/P,WU
Place of Origin:	Zhejiang, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: XHL501-509

Production Capacity: 10000000

Delivery Date: 25 working days

Shape: Others

Type: Elbow

Connection: Welding

Color: Green

Work: Water Supply

Means of Transport: Ocean,Land,Air

Packing: special export packing

Head Code: Others

Technics: Casting

Material: PP-R

Brand Name: Xinghua

Brand: Xinghua

PP-R fittings and pipe Elbow 90D from China
1:Material:PPR
2:Size:DN20-110mm
3:Color:Green,Grey,Snow White

PP-R fittings and pipe Elbow 90D from China

Material: Korea material
Pressure :1.25MPa, 1.6MPa,2.0MPa ,2.5MPa
Colors: light grey, white or other colors on request

Application cold or hot water supply, heating system including flooringheating, wall heating and radiating system, Central condition system, industrialliquids transpotation.

Features:

*Healthy and non-toxic, free of stains and scales

*High temperature resistance

*Adopting hot weiding connection for excellent welding quality of pipe andfittings, leakage effectively prevented.

*Light weight, easy to handle and transport

*Low noise, reduced by 40% compared to galvanized stee pipes

*Excellent ability in chemical corrosion resistance

*Easy and fast installation, minimized installation time and cost

*Over 50 years of service life under normal conditions.

S5 (cold water)	S (cold water)	S3.2 (hot water)	S2.5 (hot water)
20*2.0	20×2.3	20*2.8	20×3.4
25*3.2	25×2.8	25×3.5	25×4.2
32*2.9	32×3.6	32×4.4	32×5.4
40*3.7	40×4.5	40×5.5	40×6.7
50*4.6	50×5.6	50×6.9	50×8.3
63*5.8	63×7.1	63×8.6	63×10.5
75*6.8	75×8.4	75×10.3	75×12.5
90*8.2	90×10.1	90×12.3	90×15.0
110*10	110×12.3	110×15.1	110×18.3
160*14.6	160×17.9	160×21.9	160×26.6
